Aputure Amaran P60x Bi-Color Lensed LED Panel

CCT

3200K~6500K

CRI

≥95

TLCI

≥97

CQS

≥95

TM-30 RF (Average)

93

TM-30 RG (Average)

104

SSI (Tungsten)

≥84

SSI (D56)

≥72

Beam Angle (Half-Peak Angle)

45°

Max Power Output

≤60W

Max Power Consumption

≤78W

Operating Current

4.5A

Voltage (AC Power Supply)

15V DC

Voltage (D-Tap Battery)

12-16.8V DC

Voltage (NP-F Battery)

6.5V-8.4V DC

Battery Charging (Type)

Sony NP-F Style

DC Input

2-Pin DC Self-locking Waterproof

AC Power Cable

Self-locking IEC C13 AC Power Cable (1.5m)

Operating Temperature

-20°C ~ 45°C / -4°F ~ 113°F

Control Methods

On-board, Sidus Link App

Connectivity

Bluetooth 5.0 (Sidus Mesh)

Bluetooth Operating Range

≥80m / 262.5ft

Firmware Upgradeable

Sidus Link OTA

Display Type

OLED

Cooling Method

Active Cooling

Mounting

1/4-20in * 3, Tilting Support Column

Estimated LED Lifetime (L70)

50,000 Hours

Estimated Color Shift Over Lifetime (CCT)

2% over 6,000 Hours

Certifications

CE, FCC, cTUVus, KC, NCC, ROHS

Fixture

25.1*17.5*3.95cm / 9.8*6.8*1.5in

Aperture

25.07*17.37cm / 9.87*6.84in

Soft Box (Collapsed)

20*20*2.5cm / 7.87*7.87*9.84in

Soft Box (Built)

39.5*28.5*10cm / 15.55*11.22*3.94in

Carrying Case

25.7*18*9.5cm / 10.12*7.09*3.74in

Fixture

0.979kg / 2.15lbs

Soft Box

0.17kg / .37lbs

Power Supply

0.50kg / 1.1lbs

Mounting Bracket

0.24kg / .52lbs

CCT

Distance

No Softbox

With Softbox

.5M

17,570 lux / 1,632 fc

3,480 lux / 323 fc

3200K

1M

4,860 lux / 452 fc

971 lux / 90 fc

2M

1,280 lux / 119 fc

254 lux / 24 fc

3M

539 lux / 50 fc

116 lux / 11 fc

.5M

17,670 lux / 1,642 fc

3,560 lux / 331 fc

4300K

1M

4,940 lux / 459 fc

991 lux / 92 fc

2M

1,283 lux / 119 fc

261 lux / 24 fc

3M

550 lux / 51 fc

119 lux / 11 fc

.5M

18,120 lux / 1,683 fc

3,660 lux / 340 fc

5600K

1M

5,070 lux / 471 fc

1,023 lux / 95 fc

2M

1,328 lux / 123 fc

268 lux / 25 fc

3M

572 lux / 53 fc

123 lux / 11 fc

.5M

18,410 lux / 1,710 fc

3,730 lux / 347 fc

6500K

1M

5,180 lux / 481 fc

1,041 lux / 97 fc

2M

1,354 lux / 126 fc

273 lux / 25 fc

3M

585 lux / 54 fc

126 lux / 12 fc
