AJA Io Express Desktop Video Audio I/O Interface - PCIe or ExpressCard/34

AJA Io Express Desktop Video Audio I/O Interface - PCIe or ExpressCard/34
AJA Io Express Desktop Video Audio I/O Interface - PCIe or ExpressCard/34AJA Io Express Desktop Video Audio I/O Interface - PCIe or ExpressCard/34AJA Io Express Desktop Video Audio I/O Interface - PCIe or ExpressCard/34
รหัสสินค้า Io Express
หมวดหมู่ IO
ราคา 0.00 บาท
สถานะสินค้า พร้อมส่ง
อัพเดทล่าสุด 30 พ.ค. 2561
จำนวน
ชิ้น
หยิบลงตะกร้า
หนังสือรับรองบริษัท
บุ๊คแบ๊งค์
คุ้มครองโดย LnwPay

Io Express

Cross-platform monitoring and mastering.

Io Express delivers compact, powerful I/O for PC or Mac, laptop or desktop, in the field, in the studio, or wherever your work takes you

Desktop-level power to go

Io Express is the perfect Mac or PC interface for anyone who needs a quality portable monitoring and mastering solution when working with Final Cut Pro X, Avid Media Composer/Symphony/Newscutter, Adobe Creative Suite, and more.

Rugged and portable, Io Express delivers desktop-level functionality that's powerful enough to deliver in the edit suite, but sturdy and portable enough to handle life in the field. With support for a wide range of analog and digital HD/SD video and audio I/O, and broadcast-quality HD to SD down conversion, Io Express fits into any workflow with ease.

Compatible with PC or Mac, Io Express can be connected via PCIe card or ExpressCard interfaces, offering the flexibility to work on any platform, in the software of your choice.

Video Formats



  • 525i 29.97
  • 625i 25
  • 720P 50, 59.94, 60
  • 1080i 25, 29.97, 30
  • 1080PsF 23.98, 24
  • 1080p 23.98, 24, 25, 29.97, 30

Video Input


  • SD/HD SDI, SMPTE-259/292/296/424, 8- or 10-bit
  • Single Link 4:2:2 (1 x BNC)
  • HDMI v1.3 30 bits/pixel, RGB or YUV, 2.25 Gbps, SD, HD, 1080p-50/60


Video Output Digital


  • SD/HD SDI, SMPTE-259/292/296/424, 8- or 10-bit
  • Single Link 4:2:2 (1 x BNC)
  • HDMI v1.3 30 bits/pixel, RGB or YUV, 2.25 Gbps, SD, HD, 1080p-50/60


Video Output Analog


  • Composite/S-Video (Y/C) (1 x BNC)
  • NTSC, NTSCJ, PAL
  • Component (3 x BNC)
  • HD: YPbPr, RGB
  • SD: YPbPr, RGB (component mode)
  • SMPTE/EBU N10, Betacam 525 line, Betacam 525J, RGB
  • 12-bit D/A, 8x oversampling
  • +/- .2 dB to 5.0 MHz Y Frequency Response
  • +/- .2 dB to 1 MHz C Frequency Response
  • .5% 2T pulse response
  • <1% Diff Phase
  • <1% Diff Gain


Audio Input Digital


  • 8-channel, 24-bit SMPTE-259 SDI embedded audio, 48kHz sample rate, Synchronous
  • 8-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous


Audio Output Digital


  • 8-channel, 24-bit SMPTE-259 SDI embedded audio, 48kHz sample rate, Synchronous
  • 8-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous


Audio Output Analog


  • 2-channel 24-bit unbalanced audio (via RCA jack)


Reference Input or LTC Input


  • 1 BNC assignable to Reference video or LTC input
  • Reference:
    • Analog Color Black (1V) or Composite Sync (2 or 4V)
    • Non terminating
