SmartView HD

Blackmagic Design SmartView HD

Large 17 inch full HD 6RU SDI/HD-SDI/3G SDI monitoring with central software control.

        SmartView HD features an amazing 17 inch LCD screen that lets you monitor SD, HD and 3Gb/s SDI video in full resolution HD. Just as impressive is its ultra slim, 6RU rack mountable design. Only an inch thick, it’s the perfect size for all your SDI monitoring needs. What's more, SmartView HD can be conveniently adjusted from your computer via Ethernet.

Tech Specs

SDI Video Input

Automatically switches between SD, HD and 3G-SDI. Reclocked loop through output.

SDI Format Support

525i59.94, 625i50, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080p23.98, 1080p24, 1080p25, 1080p29.97,1080p30, 1080p50, 1080p59.94, 1080p60, 2048x1080p/23.98, 2048x1080p/24, 2048x1080p/25, 2048x1080PsF/23.98, 2048x1080PsF/24, 2048x1080PsF/25, 2048x1556PsF/23.98, 2048x1556PsF/24, 2048x1556PsF/25.

SDI Compliance

SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M and SMPTE 425M

SDI Auto Switching

Automatically selects between SD, HD and 3 Gb/s SDI.

Video Sampling

4:2:2 and 4:4:4
